Description
Channel mode 5 - 3
Output Power (RMS) @ 14.4 VDC:
5 Ch: 65 W x 4 + 200 W x 1 (4 ohm)
5 Ch: 105 W x 4 + 330 W x 1 (2 ohm)
3 Ch: 210 W x 2 (4 ohm) + 200 W x 1 (4 ohm)
3 Ch: 210 W x 2 (4 ohm) + 330 W x 1 (2 ohm)
Filters (Front CH, Rear CH):
Bypass - FRONT/REAR Ch: 50 - 5k Hz @ 12 dB/Oct.
Hi-Pass - SUB Ch: 50 - 500 Hz @ 24 dB/Oct.
Lo-Pass- REAR Ch: 50 - 500 Hz (Hi) @ 12 dB/Oct.
Band-Pass- 50 - 5 kHz (Lo) @ 12 dB/Oct.
Subsonic - on/off: 25 Hz @ 24 dB/Oct.
Distortion - THD (100Hz @ 4ohms) 0.02 %
S/N Ratio - (A weighted @ 1V) 100 dB
Damping factor - (100Hz @ 4ohms) 100
Size W x D x H
mm (in.) 345 x 190 x 50 / 13.58 x 7.48 x 1.97
Output Power (RMS) @ 14.4 VDC:
5 Ch: 65 W x 4 + 200 W x 1 (4 ohm)
5 Ch: 105 W x 4 + 330 W x 1 (2 ohm)
3 Ch: 210 W x 2 (4 ohm) + 200 W x 1 (4 ohm)
3 Ch: 210 W x 2 (4 ohm) + 330 W x 1 (2 ohm)
Filters (Front CH, Rear CH):
Bypass - FRONT/REAR Ch: 50 - 5k Hz @ 12 dB/Oct.
Hi-Pass - SUB Ch: 50 - 500 Hz @ 24 dB/Oct.
Lo-Pass- REAR Ch: 50 - 500 Hz (Hi) @ 12 dB/Oct.
Band-Pass- 50 - 5 kHz (Lo) @ 12 dB/Oct.
Subsonic - on/off: 25 Hz @ 24 dB/Oct.
Distortion - THD (100Hz @ 4ohms) 0.02 %
S/N Ratio - (A weighted @ 1V) 100 dB
Damping factor - (100Hz @ 4ohms) 100
Size W x D x H
mm (in.) 345 x 190 x 50 / 13.58 x 7.48 x 1.97
