- Custom 10-AWG nickel plated push terminals
- Diamond cut cast aluminum trim ring with optional grille
- Dual linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped vented backplate
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Kevlar fiber reinforced paper cone
- Protective PVC textured magnet cover
- StampCast basket with integrated spider venting
- Size: 12"
- Nominal Impedance: Dual 4-Ohm
- Power Handling: 400 Watts RMS / 800 Watts Max
- Voice Coil Diameter: 2.25" (57.7 mm)
- Magnet Weight: 72.8 oz. 2.06 kg.
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 27.2
- Re (Ohms): 6.40
- Le (mH): 5.5
- Qms: 6.30
- Qes: 0.59
- Qts: 0.54
- Vas (Liters): 81.5
- Sd (cm2): 570
- SPL (dB @ 1w/1m): 86
- Xmax (mm): 13.3
- Woofer Displacement: 0.170 cu. ft. (4.8 Liters)
- Cutout Diameter: 11.22 in. (285 mm)
- Mounting Depth: 6.40 in. (162.6 mm)
- Shipping Weight: 15.6 Lbs. (7.07 kg)
