- Custom 10-AWG nickel plated push terminals
- Diamond cut cast aluminium trim ring with optional grille
- Dual linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped vented backplate
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Kevlar fiber reinforced paper cone
- Protective PVC textured magnet cover
- StampCast basket with integrated spider venting
- Size: 15"
- Nominal Impedance: Dual 4-Ohm
- Power Handling: 400 Watts RMS / 800 Watts Max
- Voice Coil Diameter: 2.25" (57.7 mm)
- Magnet Weight: 81 oz. 2.30 kg.
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 20.9
- Re (Ohms): 6.40
- Le (mH): 5.4
- Qms: 5.70
- Qes: 0.74
- Qts: 0.66
- Vas (Liters): 219.6
- Sd (cm2): 894
- SPL (dB @ 1w/1m): 86
- Xmax (mm): 12.2
- Woofer Displacement: 0.219 cu. ft. (6.2 Liters)
- Cutout Diameter: 13.9 in. (353 mm)
- Mounting Depth: 7.34 in. (186.5 mm)
- Shipping Weight: 17.9 Lbs. (8.11 kg)
