ESX D66SP - 6 Channel DSP


Price:
£285.99

Description

Specifications

  • Digital 6-Channel Sound Processor
  • 6 x RCA Input, balanced
  • 6 x High Level Input with EPS PRO up to 40 V/RMS (via Molex )
  • 1 x USB Type B Socket for PC Software
  • 1 x RJ45 Socket for Remote Controller
  • 6 x RCA Output @ 6 V RMS
  • Dimensions 105 x 40 x 185 mm

Features

  • DSP Chip from Analog Devices™ 32 Bit, 294 MHz, Full HD Audio 96 kHz
  • Signal Converter from AKM Velvet Sound™ A/D 32 bit, D/A 32 bit
  • HPF/LPF/BP @ 6-48 dB, Phase Shift, Time Correction 0 ~ 20 ms/0.01 ms steps
  • Up to 248 output EQs, 120 input EQs (PEQ/HSLF/LSLF) +/- 12 dB, 0.5 dB steps)
  • Input Mixer, Subwoofer Control, Priority Input Mode for digital Sources
  • Input Sensitivity: Low Level 1 ~ 6 V/RMS, High Level 1 ~ 15 or 15 ~ 45 V/RMS
  • Signal-to-noise Ratio (A-weighted): Analog Input 106 dB, Digital Input 111 dB
  • Total Harmonic Distortion: Analog Input <0.0015%, Digital Input <0.0009%
  • REM OUT function for external devices, MODE switching input for e.g. convertible tops (Preset Auto Switch)
  • Optional Accessories: BT-D (Bluetooth® Modul), RC-DQ (LCD Remote Controller)
