ESX D68SP - Direction 8 Channel DSP


Price:
£324.99

Description

Specifications

  • Digital 8-Channel Sound Processor
  • 6 x RCA Input, balanced
  • 6 x High Level Input with EPS PRO up to 40 V/RMS (via Molex )
  • 1 x Optical Stereo Input, S/PDIF 192 kHz, 24 bit
  • 1 x USB Type B Socket for PC Software
  • 1 x RJ45 Socket for Remote Controller
  • 8 x RCA Output @ 6 V RMS
  • Dimensions 105 x 40 x 185 mm

Features

  • DSP Chip from Analog Devices™ 32 Bit, 294 MHz, Full HD Audio 96 kHz
  • Signal Converter from AKM Velvet Sound™ A/D 32 bit, D/A 32 bit
  • HPF/LPF/BP @ 6-48 dB, Phase Shift, Time Correction 0 ~ 20 ms/0.01 ms steps
  • Up to 248 output EQs, 120 input EQs (PEQ/HSLF/LSLF) +/- 12 dB, 0.5 dB steps)
  • Input Mixer, Subwoofer Control, Priority Input Mode for digital Sources
  • Input Sensitivity: Low Level 1 ~ 6 V/RMS, High Level 1 ~ 15 or 15 ~ 45 V/RMS
  • Signal-to-noise Ratio (A-weighted): Analog Input 106 dB, Digital Input 111 dB
  • Total Harmonic Distortion: Analog Input <0.0015%, Digital Input <0.0009%
  • REM OUT function for external devices, MODE switching input for e.g. convertible tops (Preset Auto Switch)
  • Optional Accessories: BT-D (Bluetooth® Modul), RC-DQ (LCD Remote Controller)

The prelude to the new DSP (r)evolution from ESX are the two digital sound processors from the DIRECTION series. Finest selected components, optimally tuned and combined into an ingenious overall concept, perfectly adjustable down to the smallest details with the newly developed PC software, make sound enthusiasts click their tongues respectfully. With the optional Bluetooth 5.0 upgrade set BT-D, the app version of the ESX DSP Toolkit can also be used live and in real time from the smartphone - including HD audio streaming. The RC-DQ LCD remote control, which is available as an accessory, offers additional ease of use.
