2-channel Atomo 2 Class D amplifier
Output power at 4 ohms: 2x 100Wrms / 1x 220 Wrms
Large input range 0.4Vrms - 5Vrms (LowLevel), 1.6Vrms - 20Vrms (HighLevel)
Automatic power on.
Large input range 0.4Vrms - 5Vrms (LowLevel), 1.6Vrms - 20Vrms (HighLevel)
Automatic power on.
- High / low pass filter
- Autosence performance
- Dimensions: 86 x 65 x 34 mm
- Weight: 275g
- Power: 10 - 16V
- DC-DC converter typology: uncontrolled pressure train
- External fuse: 1x 15A
- Autosense Power on: Available through high level, BTL source only
- Overall efficiency:> 75%
- Power output at 4 ohms: 2x 100W or 1x 220W
- Power output at 2 ohms: 2x 110W
- Analog input: 2x high / low level (EXT2RCA adapter available)
- Low level + high level input sensitivity range: 0.4 + 5Vrms (LL) - 1.6 + 20Vrms (HL)
- Configuration of the integrated crossover filters: AUS - LP - HP (80Hz)
- Dimensions: 86 x 65 x 34 mm
- Weight: 275g
- Colour and finish: black anodized
Note: This amplifier is designed for playing music on real speakers. It is not designed to drive static signals on purely ohmic loads.
