- Custom 10-AWG nickel plated push terminals
- Diamond cut cast aluminum trim ring with optional grille
- Dual linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped vented backplate
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Kevlar fiber reinforced paper cone
- Protective PVC textured magnet cover
- StampCast basket with integrated spider venting
- Size: 10"
- Nominal Impedance: Dual 2-Ohm
- Power Handling: 300 Watts RMS / 600 Watts Max
- Voice Coil Diameter: 2.25" (57.7 mm)
- Magnet Weight: 66.4 oz. 1.88 kg.
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 29
- Re (Ohms): 3.20
- Le (mH): 3.32
- Qms: 7.00
- Qes: 0.54
- Qts: 0.50
- Vas (Liters): 35.4
- Sd (cm2): 360
- SPL (dB @ 1w/1m): 84
- Xmax (mm): 11
- Woofer Displacement: 0.088 cu. ft. (2.5 Liters)
- Cutout Diameter: 9.13 in. (232 mm)
- Mounting Depth: 5.92 in. (150.4 mm)
- Shipping Weight: 13.6 Lbs. (6.16 kg)
